| Machine tool travel (X1/X2/Y1/Y2/Z1/Z2)(mm) | 400/400/450 |
| A/C axis (two positions) (rotational range)（°） | ±110/n×360 |
| Positioning accuracy (X1/X2/Y1/Y2/Z1/Z2)(mm) | 0.010/0.010/0.010 |
| A/C axis (two positions) (positioning accuracy)（″） | 20 |
| Repeatability (X1/X2/Y1/Y2/Z1/Z2)(mm) | 0.005 |
| A/C axis (Repeatability)（″） | 10 |
| Laser average power(w) | 80(单工位40) |
| Laser pulse width(fs) | fs级 |
| Table diameter(mm) | 200 |
| Maximum load of workbench(kg) | 10 |
| Equipment weight（kg） | 11000 |
| Equipment size (kg)(W X D X H) | 4700X5000X2800 |
